C1238

C1238-00-DRIVE TEST: UNSUCCESSFUL

For a complete wiring diagram, refer to the Wiring Information.

- When Monitored:
During the Drive Test.

- Set Condition:
If the Anti-Lock Brakes System (ABS) Module detects a fault with the Brake Pedal Position Sensor, Steering Angle Sensor, the Pressure Sensor, or the Dynamics Sensor.





NOTE: If any other DTCs are present, repair them first before continuing with this diagnostic procedure.
VERIFY THE DTC IS ACTIVE

NOTE: This DTC must be active for the results of this test to be valid.

1. Turn the ignition on.
2. With the scan tool, read and record DTCs.
3. With the scan tool, erase DTCs.
4. Start the engine.
5. With the scan tool, read and record DTCs.

Is the DTC active at this time?

Yes

- Replace the Anti-Lock Brake System (ABS) Module. Anti-Lock Brake System Module - Removal.
- Perform the ABS VERIFICATION TEST. ABS Verification Test.

No

- Test complete.
