Park Assist Module (PAM)

B222A-00-VEHICLE LINE MISMATCH

For a complete wiring diagram, refer to the Wiring Information.

- When Monitored:
With the ignition on.

- Set Condition:
If the Vehicle Line data transmitted on the CAN C Interior bus doesn't correspond with the data stored in the Park Assist Module.





CHECK VEHICLE LINE IN THE BCM
1. With the scan tool, compare the vehicle line that is programmed in to the BCM to the vehicle line of the vehicle.

Does the vehicle line programmed into the BCM match the vehicle?

Yes

- Replace the Park Assist Module. Park Assist Module - Removal.
- Perform the BODY VERIFICATION TEST. Body Verification Test.

No

- Use the scan tool to read DTCs in all other modules. If any communication DTCs are present, perform the appropriate diagnostic procedure. Perform any Technical Service Bulletins that apply. If no problems are found, test is complete.
- Perform the BODY VERIFICATION TEST. Body Verification Test.
