B2219-96

B2219-96-(PDM) PASSENGER DOOR MODULE INTERNAL - COMPONENT INTERNAL FAILURE

For a complete wiring diagram, refer to the Wiring Information.

- When Monitored:
At all times.

- Set Condition:
Whenever the module detects an EEPROM failure





Replace the Passenger Door Module

NOTE: Anytime this code is logged, the module must be replaced.

Repair

- Replace the Passenger Door Module.
- Perform the BODY VERIFICATION TEST. Door Module - Removal.
