B1BC7

B1BC7-00-DEPLOYMENT DATA RECORD FULL

For a complete wiring diagram, refer to the Wiring Information.

Theory of Operation
When powered, the Occupant Restraint Controller (ORC) performs an internal self test. The repair of this fault condition does not involve any external circuitry and centers on verifying the integrity of the module's internal memory.
- When Monitored:
The ORC checks its internal memory for the number of recorded deployment events once at every power up, during the initialization process.

- Set Condition:
This DTC sets when the ORC detects that five recorded deploy events have been reached. Once set, this DTC is latched indefinitely.





Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Restraints System Pre-Diagnostic Procedure.

1. CHECK FOR ACTIVE DTC
1. Turn the ignition on.
2. With the scan tool, read ORC DTCs.

Is the Deployment Data Record Full DTC active?

Yes

- Go To 2

No

- Perform the RESTRAINTS SYSTEM VERIFICATION TEST.Restraints System Verification Test.

2. REPLACE THE OCCUPANT RESTRAINT CONTROLLER (ORC)

WARNING: Turn the ignition off disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury.

WARNING: If the airbag control module is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental airbag deployment and serious or fatal injury.

Repair

- Replace the Occupant Restraint Controller (ORC). Occupant Restraint Controller - Removal.
- Perform the RESTRAINTS SYSTEM VERIFICATION TEST. Restraints System Verification Test.
