B1A7D-2A

B1A7D-2A-START BUTTON - STUCK





For a complete wiring diagram, refer to the Wiring Information.

- When Monitored:
Each time the Start/Stop Button is pressed.

- Set Condition:
If the (D122) Security K Line Communication circuit and the (G201) Ignition Switch Position Signal circuit match, during a button press, but are On for longer than 25 seconds, this code will set.





1. CHECK FOR AN ACTIVE DTC
1. Using the scan tool, record and erase the DTCs.
2. Turn the ignition to the Lock position.

NOTE: Do not apply the brake or the clutch in the next step.

3. Press the KIN in all positions several times.
4. Turn the ignition off and then back on.
5. Using the scan tool, read the active DTCs.

Does the scan tool display; B1A7D-2A-START BUTTON - STUCK?

Yes

- Go To 2

No

- Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and poor pin fit.
- Perform the BODY VERIFICATION TEST. Body Verification Test.

2. EXAMINE THE KEYLESS IGNITION NODE
1. Check for anything that could cause the button to stick.

Could you find anything that would cause a sticking condition?

Yes

- Repair as necessary.
- Perform the BODY VERIFICATION TEST. Body Verification Test.

No

- Replace the Keyless Ignition Node (KIN). Keyless Ignition Node Receiver - Removal.
- Perform the BODY VERIFICATION TEST. Body Verification Test.
