B1572

B1572-00-CD/DVD READ ERROR - INOPERABLE DISC

For a complete wiring diagram, refer to the Wiring Information.

- When Monitored:
Continuously with the ignition on and the Radio/CD/DVD player turned on.

- Set Condition:
The code will set if a CD/DVD is scratched, damaged, or contains corrupt data.





RADIO/CD/DVD PLAYER
1. Replace the problem CD/DVD with a good, clean, unscratched CD/DVD.
2. Turn the Radio/CD/DVD player on.
3. With the scan tool, read DTCs.

Does the scan tool display active: B1572-00-CD/DVD READ ERROR- INOPERABLE DISC?

Yes

- Eject the inoperative CD/DVD and replace the Radio/CD/DVD player.
- Perform the BODY VERIFICATION TEST. Body Verification Test.

No

- Test Complete.
