Sedan

PASSENGER WINDOW NOT CALIBRATED/LOST CALIBRATION - JS41 ONLY

For a complete wiring diagram, refer to the Wiring Information.






NOTE: This condition can happen anytime the battery or the door module connector is disconnected.

1. WINDOW MOTOR NOT CALIBRATED
1. Move the window part way down.
2. Run the window to the full up position and continue to hold the switch for an additional 2 seconds.
3. Run the window to the full down position and continue to hold the switch for an additional 2 seconds.
4. Press and release the switch to the express up position.

Did the window move to the full up position?

No

- Go To 2

Yes

- Test complete.

2. EXPRESS SWITCH

Is the express feature inoperative from both front door switches?

Yes

- Replace the Passenger Door Module.
- Perform the BODY VERIFICATION TEST. Body Verification Test.

No

- Replace the defective Express Window Switch assembly.
- Perform the BODY VERIFICATION TEST. Body Verification Test.
