Differential Seal - Removal

REMOVAL






NOTE: Right side shown, left side similar.

1. Remove the half shaft Half Shaft - Removal.

NOTE: Some transaxle fluid may spill when the transmission extension assembly (2) is removed.

2. Remove the transmission extension assembly (2) bolts (six bolts for left side, four bolts for right side) and remove the assembly (1).
