Sedan

INSTALLATION





1. Install the power seat switches to the side shield, if equipped.
2. Connect the electrical connector, if equipped.
3. Position the front of the side shield to the seat frame engaging the plastic tab to the front of the seat frame and slide the shield reward.
4. Push the side shield inward to engage the middle spring clip retainer.
5. Carefully engage the upper and rear plastic tabs on the shield to the seat frame.
6. Install the fastener (1) attaching the side shield to the bottom of seat frame.





7. Install the seat belt (2) to the seat and install the seat belt anchor bolt (3). Tighten to 40 Nm (30 ft. lbs.).
8. Install the seat belt cover (4) to the side shield (1).





9. Install the clip (2) to the recliner handle (1) as shown.





10. Install the recliner handle, ensuring the clip engages to the spline.
11. Install the seat into the vehicle. Seat - Installation.
