Powertrain Control Module (PCM) - 62TE

U0121-LOST COMMUNICATION WITH ABS

For a complete wiring diagram, refer to the Wiring Information.

- When Monitored:
Ignition run time is greater than one second.

Battery voltage between 9 and 16 volts.

Engine run time greater than three seconds.

- Set Condition:
Bus messages not received from the Totally Integrated Power Module (TIPM) for approximately two to five seconds.





ACTIVE DTC
1. Ignition on, engine not running.
2. With the scan tool, select view DTCs.

Is the DTC Active at this time?

Yes

- Testing and Inspection and perform the U0121-Lost Communication with Anti-Lock Brake Module diagnostic procedure.

No

- Stored Lost Communication DTCs and perform the Stored Lost Communication DTCs diagnostic procedure.
