P1C4E

P1C4E-FAULT IN ABS/ESP MODULE

For a complete wiring diagram, refer to the Wiring Information.

- When Monitored:
Ignition on and battery voltage greater than 10.0 Volts.

- Set Condition:
An active DTC is stored in the ABS/ESP Module. One Trip Fault. Three good trips to turn off the MIL.





Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Pre-Diagnostic Troubleshooting Procedure.
DTC PRESENT IN TRANSMISSION CONTROLLER
1. This is an informational DTC to inform you that a DTCs is stored in the Anti-Lock Brake Module.
2. Erase this DTC after all ABS DTCs have been repaired.
3. Using a scan tool, read the Anti-Lock Brake DTC. Testing and Inspection.

PCM Diagnostic Information complete.

Continue

- Test Complete.
