B2182

B2182-HEATED SEAT MODULE POWER SUPPLY HIGH

For a complete wiring diagram, refer to the Wiring Information.

- When Monitored:
During heated seat operation.

- Set Condition:
This code is set immediately if the Heated Seat Module detects voltage over 16.0 volts on the (F937) Fused Ignition Switch Output (Run) circuit.





CHECK PCM FOR CHARGING SYSTEM DTC
1. With the scan tool, record and erase DTCs.
2. Cycle the ignition switch from On to Off.
3. Start the engine.
4. Run the engine at approximately 1500 RPM for 1 minute.
5. With the scan tool, read DTCs.
6. With the scan tool, read PCM DTCs.

Are there any Charging System DTCs set in the PCM?

Yes

- Charging System and Testing and Inspection for Charging System diagnostic procedures.

No

- The conditions that caused this code to set are not present at this time. Check the charging system.
- Perform BODY VERIFICATION TEST. Body Verification Test.
