Driver Door Module (DDM)

B210E-BATTERY VOLTAGE HIGH

For a complete wiring diagram, refer to the Wiring Information.

- When Monitored:
At all times.

- Set Condition:
Anytime the module senses voltage input above 15.9 volts for over 15 seconds, this code will set.





1. CHECK POWERTRAIN CONTROL MODULE DTCs
1. With the scan tool, read Powertrain Control Module (PCM) DTCs.

Are there any Charging or Starting DTCs Active?

No

- Go To 2

Yes

- Testing and Inspection and perform the appropriate diagnostic procedure.

2. TEST FOR INTERMITTENT CONDITION
1. With the scan tool, record and erase the DTCs.
2. Start the engine and run for two minutes.
3. With the scan tool, read the active DTCs.

Does the scan tool display B210E-BATTERY VOLTAGE HIGH?

Yes

- Replace the Driver Door Module.
- Perform the BODY VERIFICATION TEST. Body Verification Test.

No

- The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors.
- Perform the BODY VERIFICATION TEST. Body Verification Test.
