B1A6B

B1A6B-STEERING COLUMN LOCK MODULE NOT INITIALIZED

For a complete wiring diagram, refer to the Wiring Information.

- When Monitored:
Continuously.

- Set Condition:
The Wireless Control Module (WCM) (SKREEM) detects that the Steering Column Lock Module has not initialized. The WCM has been enabled with the Steering Wheel Lock Module but did not personalized





1. STEERING COLUMN LOCK MODULE
1. With the scan tool, record and erase the WCM DTCs.
2. Remove and insert the key from the ignition switch several times then leave the key in the run position.
3. With the scan tool, read the DTCs.

Does the scan tool display: B1A6B STEERING COLUMN LOCK MODULE NOT INITIALIZED?

Yes

- Go To 2

No

- Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the wiring diagrams as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and correct pin tension.

2. INITIALIZE STEERING COLUMN LOCK MODULE
1. With the scan tool, erase the DTCs in the WCM.
2. With the scan tool, perform the Steering Wheel Lock Module (ELV) Replaced routine.
3. Turn the Ignition off, wait 15 seconds then turn the ignition back on.
4. Remove and insert the key from the ignition switch several times then leave the key in the run position.
5. With the scan tool, read the DTCs.

Does the scan tool display: B1A6B STEERING COLUMN LOCK MODULE NOT INITIALIZED?

Yes

- Replace the Steering Column Lock Module. The Wireless Control Module (WCM) must also be replaced along with the Steering Column Lock Module (ELV). When replacing the WCM and the Steering Column Lock Module (ELV), the WCM MUST be programmed BEFORE the Steering Column Lock Module (ELV) is programmed..
- Replace and program the Wireless Control Module (WCM) (SKREEM). Sentry Key Immobilizer Module (SKREEM) - Removal.
- Replace and program the Steering Column Lock Module (ELV). Shaft Lock Module - Removal.
- Perform the WIRELESS CONTROL MODULE (WCM) VERIFICATION Test. Wireless Control Module (WCM) Verification.

No

- Test complete
- Perform the BODY VERIFICATION TEST. Body Verification Test.
