P054A

P054A-CAMSHAFT POSITION TIMING OVER - ADVANCED - BANK1

- When Monitored:
Engine cranking and engine running

- Set Condition:
If the Camshaft Position Signal (angular variation) is more than 15° of the Crankshaft Position Signal, this DTC is set.





For a complete wiring diagram, refer to the Wiring Information.

1. CHECK FOR CURRENT DTC
1. Turn the ignition on.
2. With the scan tool, read PCM DTCs.

Is this DTC present?

Yes

- For complete diagnosis of this DTC, refer to (P0341) CAMSHAFT POSITION TIMING OVER-RETARDED.

No

- Go To 2

2. INTERMITTENT WIRING AND CONNECTORS
1. The conditions necessary to set this DTC are not present at this time.

NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs.Using the wiring diagram/schematic as a guide, inspect the wiring and connectors specific to this DTC. Wiggle the wires while checking for shorts and open circuits.

NOTE: Check for any Technical Service Bulletins that may apply.

Were there any problems found?

Yes

- Repair as necessary.
- Perform the POWERTRAIN VERIFICATION TEST. Powertrain Verification Test.

No

- The condition that caused this DTC to set is currently not present. Inspect the related wiring harness for a possible intermittent condition.
