Supply Hose

2.0L/2.4L ENGINE





1. Slide hose clamps (2) onto both ends of the power steering fluid supply hose (1) far enough to clear the fittings on the reservoir and pump once the hose is installed.
2. Place the pump end of the supply hose (1) onto the pump supply fitting (3). Expand the hose clamp (2) and slide it over the hose and pump supply fitting. Secure the clamp once it is past the bead formed into the fluid supply fitting.





3. Place the fluid reservoir end of the supply hose (4) onto the reservoir (5) supply fitting. Expand the hose clamp and slide it over the hose and fitting. Secure the clamp once it is past the bead formed into the fluid reservoir fitting.
4. Fill and bleed the power steering system. Power Steering System Bleeding
5. Check for leaks.
