B235A

B235A-PRODUCTION MODE



- When Monitored:
Continuously.

- Set Condition:
The Power Top Control Module Production Mode has been set active.





Always perform the Power Top System Pre-Diagnostic procedure before proceeding. Power Top System Pre-Diagnostic Procedure.
DISABLE PRODUCTION MODE IF ACTIVE
1. With the scan tool, read the active PTCM DTCs.

Does the scan tool display this DTC as active?

Yes

- Using the scan tool, disable Production Mode.
- Perform the BODY VERIFICATION TEST. Body Verification Test.

No

- If the DTC is stored, erase the DTC.
