B2207

B2207-OCCUPANT RESTRAINT CONTROLLER INTERNAL 1



- When Monitored:
With the ignition on. The modules on board diagnostics continuously performs internal circuit tests.

- Set Condition:
This DTC will set if the module identifies an out of range internal circuit.





CHECK FOR SQUIB RELATED DTCS
1. Turn the ignition on.
2. With the scan tool, read the Occupant Restraint Controller (ORC) DTCs.

Is there any squib related DTCs present?

Yes

- Diagnose specified squib DTCs before diagnosing this DTC.
- Testing and Inspection Perform the appropriate diagnostic procedure.

No

- WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury.

- WARNING: If the Occupant Restraint Controller (ORC) is dropped at any time, it must be replaced. Failure to follow these instructions may result in possible serious or fatal injury.

- Replace the ORC.
- Perform the OCCUPANT CLASSIFICATION MODULE SYSTEM VERIFICATION TEST. Airbag System Verification Test.
