B1BC7

B1BC7-DEPLOYMENT DATA RECORD FULL



- When Monitored:
With the ignition on. The Occupant Restraint Controller (ORC) on board diagnostics continuously monitors the deployment register.

The register counts the number of airbag deployment for this vehicle.

- Set Condition:
This DTC will set if the ORC deployment register increments to 3.





REPLACE THE OCCUPANT RESTRAINT CONTROLLER

WARNING: Turn the ignition off, disconnect the 12-volt battery and wait two minutes before proceeding. Failure to follow these instructions may result in possible serious or fatal injury.

WARNING: If the Occupant Restraint Controller (ORC) is dropped at any time, it must be replaced. Failure to follow these instructions may result in possible serious or fatal injury.

View repair.

Repair

- Replace the Occupant Restraint Controller.
- Perform the AIRBAG SYSTEM VERIFICATION TEST.Airbag System Verification Test.
