NGC

P0630-VIN NOT PROGRAMMED IN PCM

For a complete wiring diagram Consult Diagrams/Electrical.

- When Monitored:
At initialization.

- Set Condition:
The VIN has not been programmed into the PCM. One Trip Fault. Three good trips to turn off the MIL.





Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding.Initial Inspection and Diagnostic Overview

Diagnostic Test

1. VIN NOT PROGRAMMED IN THE POWERTRAIN CONTROL MODULE (PCM)
Turn the ignition on.
Using the scan tool, program the VIN into the Powertrain Control Module (PCM).
Start the engine and allow it to reach normal operating temperature.

NOTE: If the engine will not start, crank the engine for 15 seconds. Crank at least 2 times with the ignition switch returning to the off position each time.

With a scan tool, select View DTCs.
Is the DTC Active at this time?

Yes

- Replace and program the Powertrain Control Module (PCM).
- Perform the PCM Verification Test. Powertrain Verification Test

No

- Test complete.
- Perform the PCM Verification Test. Powertrain Verification Test
