GPEC

P0630-VIN NOT PROGRAMMED IN PCM

For a complete wiring diagram Consult Diagrams/Electrical.

- When Monitored:
At initialization.

- Set Condition:
The VIN has not been programmed into the PCM. One Trip Fault. Three good trips to turn off the MIL.





Always perform the Pre-Diagnostic Troubleshooting procedure before proceeding. Initial Inspection and Diagnostic Overview.

Diagnostic Test

1. VIN NOT PROGRAMMED IN THE POWERTRAIN CONTROL MODULE (PCM)
Ignition on, engine not running.
Using the scan tool, program the VIN into the Powertrain Control Module (PCM).
Start the engine and allow it to reach normal operating temperature.

NOTE: If the engine will not start, crank the engine for 15 seconds. Crank at least 2 times with the ignition switch returning to the off position each time.

With a scan tool, select View DTCs.
Is the status Active for this DTC?

Yes

- Replace and program the Powertrain Control Module (PCM).
- Perform the PCM Verification Test Ver. 1Powertrain Verification Test.

No

- Test complete.
- Perform the PCM Verification Test Ver. 1Powertrain Verification Test.
