B2182

B2182- HEATED SEAT MODULE POWER SUPPLY HIGH

For a complete wiring diagram Consult Diagrams/Electrical.

- When Monitored:
During heated seat operation.

- Set Condition:
This code is set immediately if the Heated Seat Module detects voltage over 16.0 volts on the (F937) Fused Ignition Switch Output (Run) circuit.





Diagnostic Test

1. CHECK PCM FOR CHARGING SYSTEM DTC
With the scan tool, record and erase DTC's.
Cycle the ignition switch from On to Off.
Start the engine.
Run the engine at approximately 1500 RPM for 1 minute.
With the scan tool, read DTCs.
With the scan tool, read Powertrain Control Module DTC's.
Are there any Charging System DTC's set in the Powertrain Control Module?

Yes

- Diagnose and repair the DTC(s).
- Perform BODY VERIFICATION TEST - VER 1.Body Verification Test

No

- The conditions that caused this code to set are not present at this time. Using Service Information, check the charging system.
- Perform BODY VERIFICATION TEST - VER 1.Body Verification Test
