2nd Row

REMOVAL





1. Disconnect and isolate the battery negative cable.
2. Remove the rear floor console Floor Console - Removal.
3. Remove the rear floor console switch bezel (1) by releasing the retaining tab (3) located at each end of the switch bezel and pushing it out through the front surface of the console (6).
4. Disconnect the heated seat switch wire harness connector (4).




5. From the back of the rear floor console switch bezel (1), gently pry the switch free from the bezel (2).
