Seat Riser - Installation







INSTALLATION





1. Place seat base into position on second seat assembly.
2. Install four nuts attaching seat base to seat assembly.
3. Place seat into position.
4. Connect heating element wire harness.
5. Install second row seat. Seat - Installation.
6. Install headrest. Headrest - Installation.
7. Disconnect and isolate the battery negative cable.
