Removal

REMOVAL





NOTE: The liftgate does not have an outside mechanical release. For any service procedures that require disconnecting battery, open liftgate, if necessary before disconnecting battery.

1. Release liftgate latch and open liftgate.
2. Open hood, disconnect and isolate the battery negative cable.
3. Remove liftgate inner trim panel.
4. Disconnect the liftgate light bar electrical connector.




5. Remove the four liftgate light bar retaining screws.
6. Using a Trim Stick C-4755 or equivalent, gently pry out wiring grommet to liftgate light bar.
7. Remove liftgate light bar from vehicle.
