B224E

B224E-POWER LIFTGATE MODULE INTERNAL

For a complete wiring diagram Consult Diagrams/Electrical

- When Monitored:
Whenever the battery is connected.

- Set Condition:
When the module senses an internal problem, this code will set.





Diagnostic Test

1. DTC PRESENT
With the scan tool, record and erase DTC's.
Cycle the ignition switch from On to Off.
Wait 30 seconds.
Turn the ignition on.
With the scan tool, read DTCs.
Does the scan tool display POWER LIFTGATE MODULE INTERNAL?

No

- Operate the power liftgate open and closed several times. With the scan tool, read DTC's. If this code appears, replace the Power Liftgate Module .
- PERFORM BODY VERIFICATION TEST - VER 1. Body Verification Test.

Yes

- Replace the Power Liftgate Module.
- PERFORM BODY VERIFICATION TEST - VER 1.Body Verification Test.
