B2201

B2201-CALIBRATION MISMATCH

- When Monitored:
With the Ignition on.

- Set Condition:
This DTC will be set when the CAN signals indicate that the vehicle is not configured as the Occupant Restraint Controller (ORC) expects the vehicle to be configured. The ORC does not support a stored B2201 DTC.





Diagnostic Test

1. VERIFY THAT DTC B2201-CALIBRATION MISMATCH IS ACTIVE
Turn the ignition on.
With the scan tool, read ORC DTCs.

NOTE: Ensure the battery is fully charged.

Does the scan tool display active: B2201-CALIBRATION MISMATCH?

Yes

- Go To 2

No

- Test Complete.


2. CHECK VIN IN PCM
With the scan tool compare the VIN that is programmed into the PCM to the VIN stored in the ORC.
Does the VIN programmed into the PCM match the VIN stored in the ORC?

Yes

- Go To 3

No

- Replace and program the Powertrain Control Module. Ensure the PCM is replaced with the correct vehicle line PCM.
- PERFORM NGC POWERTRAIN VERIFICATION TEST . Powertrain Verification Test

3. REPLACE THE OCCUPANT RESTRAINT CONTROLLER
WARNING: To avoid serious or fatal injury, turn the ignition off, disconnect the battery and wait two minutes before proceeding.

WARNING: If the airbag control module is dropped at any time, it must be replaced. Failure to take the proper precautions can result in accidental airbag deployment and serious or fatal injury.

View repair.

Repair

- Replace the Occupant Restraint Controller.
- PERFORM *ORC VERIFICATION TEST - VER 1. Occupant Restraint Controller (ORC) Verification Test
