Removal

REMOVAL

1. Support the transmission.
2. Remove the propeller shaft. Propeller Shaft - Removal.




3. Hold the output flange (3) with Special Tool C-3281 (2) Flange Wrench while removing the collared nut (1).




4. Remove the output flange (3) from output shaft (1).

NOTE: Do not score the transmission seal bore.

5. Pry out transmission output flange seal (2) with a screwdriver.
