Maintenance Schedules Defined

There are two maintenance schedules that show the required service for your vehicle.

Schedule A typically rotates with Schedule B. Follow Schedule A after the first service interval, Schedule B after the second service interval, and so on. In some cases where the service interval has been extended due to very light duty driving, a Schedule B service may be indicated following a previous Schedule B service. There are additional service tasks required under Schedule B.

Your Flexible Service System (FSS) should give you an exact indication of when your vehicle should be scheduled for service and which schedule to follow.

Additional Periodic Maintenance items should also be performed beyond the items listed in the following charts to assure the optimum performance of your Crossfire.

FSS SYSTEM

The Flexible Service System (FSS) permits a flexible service schedule that is directly related to the operating conditions of the vehicle.

The oil change interval for your Crossfire is initially set at 7,000 miles (11,000 km). Very light duty driving cycles (most trips more than 10 miles [16 km] at moderate speeds in moderate temperature conditions) can extend the service interval beyond 7,000 miles (11,000 km). If ANY of the following apply to your driving, the oil change interval can be reduced significantly:

- Day or night temperatures are below 32�F (0�C).
- Stop and go driving.
- Extensive engine idling.
- Driving in dusty conditions.
- Short trips of less than 10 miles (16 km).
- More than 50% of your driving is at sustained high speeds during hot weather, above 90�F (32�C).

There are two symbols which will appear in the main odometer display field prior to the next suggested service.






This symbol represents Service A.






This second symbol represents Service B. Service B rotates with Service A and includes additional service tasks.






The next service is normally calculated and displayed next to the Service A or Service B symbol as distance remaining before the next service is required.






Depending on operating conditions throughout the year, a clock symbol may appear next to the service symbol. When this occurs, the next service is calculated and displayed in days remaining before the next service is required.

You should have the maintenance performed within the stated time period or distance.

Following a completed A or B service your authorized dealer sets the counter to 7,000 miles (11,000 km).

NOTE: When disconnecting vehicle battery for one or more days at a time, such days will not be counted. Any such days not counted by FSS can be added by your authorized dealer.

The interval between services is determined by the type of vehicle operation. Driving at extreme speeds, and cold starts combined with short distance driving in which the engine does not reach normal operating temperature, reduce the interval between services.

Regardless of the service interval determined by your FSS, the scheduled services as posted in this manual must be followed to properly care for your vehicle.
