Tail Lamp Unit - Installation

TAIL LAMP UNIT





1. Insert the tail lamp unit into the rear body panel (1) and install the retaining nuts. Tighten to 2 Nm (+/- 0,3 Nm) (18 in. lbs.).
2. Connect the harness connector and install the access panel into the rear cargo area interior trim panel.
3. Connect the negative battery cable.
