Tonneau Cover Latch

TONNEAU COVER LATCH





NOTE: If installing the present latch, use the alignment marks from the removal to install the latch. If there are no alignment marks present, or if a new latch is being installed, Convertible Top - Standard Procedure.

1. Install the tonneau cover latch assembly (2). Tighten screws (1) to 8 Nm (71 in. lbs.).
2. Connect the hydraulic lines (3) to the latch assembly.
3. Connect the tonneau cover latch harness connector.
4. Manually lower and lock the tonneau cover.
5. Connect the negative battery cable.
