P0219

P0219 - ENGINE OVERSPEED





When Monitored and Set Condition

- When Monitored: Valid Engine RPM message received at least once, the CAN BUS Circuit and Engine CAN Message Missing are not active.
- Set Condition: If the engine speed increases above 5100 RPM.





For a complete Transmission Control Module Circuit Diagram, [1][2]Automatic Transmission/Transaxle.

Diagnostic Test

1. PRE-DIAGNOSTIC CHECK OUT
NOTE: Low fluid level can be the cause of many transmission problems. If the fluid level is low, locate and repair the leak then check and adjust the fluid level.

NOTE: Always perform diagnostics with a fully charged battery to avoid false symptoms.

With the scan tool, read Engine DTCs. Check and repair all engine DTCs prior to performing transmission symptom diagnostics.
With the scan tool, read and record all Transmission DTCs.

NOTE: Check connectors - Clean/repair as necessary. Poor pin to terminal connections can set DTCs.

Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Repair as necessary.
Most DTCs set on start up but some must be set by driving the vehicle such that all diagnostic monitors have run.

NOTE: Check for any Technical Service Bulletins that may apply.

Perform this procedure prior to Symptom diagnosis.

Continue

Go To 2

2. ENGINE - MECHANICAL PROBLEM
Determine if any Engine Mechanical problems are present.
Are any Engine Mechanical problems present?

Yes

- Refer to Engine for the proper repair procedure.

No

Go To 3

3. TRANSMISSION - MECHANICAL PROBLEM
Determine if there are any Transmission Mechanical problems present.
Remove the Transmission Oil Pan and inspect for debris or a plugged Transmission Oil Filter.
Is there any debris, plugged Transmission Oil Filter, or signs of an internal transmission problem?

Yes

- Refer to Transmission for the proper repair procedure.

No

Go To 4

4. PCM - ENGINE OVERSPEED
NOTE: The Engine and Transmission must not have mechanical problems and be operating normally before proceeding with this test.

Turn the ignition off.
Replace and program the Powertrain Control Module. Powertrain Control Module - Removal.
With the scan tool, erase Transmission DTCs.
Road test the vehicle.
With the scan tool, read Transmission DTCs.
Did DTC (P0219) ENGINE OVERSPEED set again?

Yes

- Replace the Transmission Control Module. Transmission Control Module - Removal.
- Perform NAG1 TRANSMISSION VERIFICATION TEST. Transmission Verification Test

No

Test Complete.
