Power Top Control Module (PTCM) EEPROM Timing

9004 - POWER TOP CONTROL MODULE (PTCM) EEPROM TIMING





1. DTC Present in the Power Top Control Module (PTCM)

NOTE: This is an informational DTC reporting that the Power Top Control Module has indicated an internal EEPROM timing glitch. This DTC does not indicate a fatal error in the PTCM and should not be replaced. The Power Top will work as designed with the DTC set.

With the scan tool, read and record the PTCM DTCs and then erase the PTCM DTCs
Perform 3 ignition key cycles, leaving the ignition key on for a minimum of 90 seconds per cycle.
Erase this DTC from the PTCM after any other PTCM DTC(s) have been repaired.
PTCM Diagnostic Information complete.

Continue

- Test Complete.
