Removal

2.7L




1. Inlet Air Temperature (IAT) location.




2. Disconnect negative battery cable.

3. Unlock electrical connector.

4. Disconnect electrical connector.

5. Turn sensor 1/4 turn and pull to remove sensor.

6. Remove sensor.
