Removal

REMOVAL





1. Remove B-pillar trim panel (4).

2. Remove bolt (3) attaching turning loop (2) to belt height adjuster (1).





3. Remove bolt (3) attaching seat belt height adjuster (4) to B-pillar.

4. Remove seat belt height adjuster (4) from vehicle.
