Non-Pressure System

NON-PRESSURE SYSTEM




1. Connect the overflow hose (4) to the radiator nipple (2).
2. Install container in mounting position and install mounting bolts (1).
3. Tighten mounting bolts to 10 Nm (89 in. lbs.).
4. Fill cooling system.
