Removal

REMOVAL





FRONT DOOR

NOTE: Secure window in the UP position before removing motor.

1. Disconnect and isolate the battery negative cable.

2. Remove the front door trim panel.

3. Remove the front door speaker.

4. Remove the watershield.

5. Disconnect electrical harness wire connector from the motor.

6. Remove mounting fasteners and motor.

REAR DOOR

NOTE: Secure window in the UP position before removing motor.

1. Disconnect and isolate the battery negative cable.

2. Remove the rear door trim panel.

3. Remove the rear door speaker.

4. Remove the watershield.

5. Disconnect electrical harness wire connector from the motor.

6. Loosen window regulator mounting fasteners (do not remove).

7. Remove mounting fasteners and motor.
