Auto Door Locks Inoperative

*AUTO DOOR LOCKS INOPERATIVE

For a complete wiring diagram refer to Diagrams/Electrical.





Diagnostic Test

1. READ AUTO DOOR LOCK STATUS ON DRB

With the scan tool, under "CUSTOMER PREFERENCES" read the "Auto Door Lock" status.

Does the scan tool show AUTO DOOR LOCKS ENABLED ?

Yes

- Go To 2

No

- With the scan tool, enable the Auto Door Locks and retest the System.
- Perform the BODY VERIFICATION TEST - VER 1. Body Verification Test

2. CHECKING PCM DTC'S

With the scan tool, read ENGINE DTC's.

Are there any TPS or VEHICLE SPEED DTC's present?

Yes

- Refer to DRIVEABILITY for the related symptom(s).
- Perform the BODY VERIFICATION TEST - VER 1. Body Verification Test

No

- Replace the Driver Door Module.
- Perform the BODY VERIFICATION TEST - VER 1. Body Verification Test
