Software Checksum Failure - Amplifier

SOFTWARE CHECKSUM FAILURE - AMPLIFIER

For a complete wiring diagram refer to Diagrams/Electrical.

- When Monitored:

When the scan tool performs the PCI Amplifier Test.

- Set Condition:

When the Amplifier detects a fault with the software checksum.





Diagnostic Test

1. AMPLIFIER

NOTE: The fault condition must be present to continue diagnosis. Use the scan tool to perform the Amplifier pretest to verify the fault condition is present before continuing diagnosis.

Turn the ignition on.

With the scan tool, perform the Amplifier pretest.

Is the fault condition present?

Yes

- Replace the Amplifier.
- Perform the BODY VERIFICATION TEST - VER 1. Body Verification Test

No

- Refer to the wiring diagrams to help isolate a possible intermittent condition.
- Perform the BODY VERIFICATION TEST - VER 1. Body Verification Test
