P0755
Symptom: P0755-2/4 SOLENOID CIRCUITWhen Monitored and Set Condition:
When Monitored: Initially at power-up, then every 10 seconds thereafter. Also, immediately after a gear ratio or pressure switch error is detected.
Set Condition: Three consecutive solenoid continuity test failures, or one failure if test is run in response to a gear ratio or pressure switch error.
POSSIBLE CAUSES
- RELATED TCM POWER INPUT DTCS PRESENT
- TRANSMISSION CONTROL RELAY OUTPUT CIRCUIT OPEN
- 2/4 SOLENOID CONTROL CIRCUIT OPEN
- 2/4 SOLENOID CONTROL CIRCUIT SHORT TO GROUND
- 2/4 SOLENOID CONTROL CIRCUIT SHORT TO VOLTAGE
- 2/4 SOLENOID
- POWERTRAIN CONTROL MODULE
- INTERMITTENT WIRING AND CONNECTORS
