Dimming Level Switch Input Failure

Test 1 - Test 2:

Test 3 - Test 5:

SYMPTOM
DIMMING LEVEL SWITCH INPUT FAILURE

WHEN MONITORED
Continuously.

SET CONDITION
BCM detects an open or short circuit condition for 10 consecutive seconds on the dimming level switch input.

POSSIBLE CAUSES
- Intermittent condition
- Open circuit
- Short to ground
- Short to battery
- Failed dimmer switch
- Body control module
