Airbag Lamp Circuit Open

Test 1 - Test 2:

SYMPTOM
AIRBAG LAMP CIRCUIT OPEN

TEST NOTE
This symptom is diagnosed using the test ABS LAMP CIRCUIT OPEN.

WHEN MONITORED
The Instrument Cluster performs an internal diagnostic of the circuit at power up and when the bulb is requested.

SET CONDITION
When the Instrument Cluster is detects a fault in the Airbag bulb circuit.

POSSIBLE CAUSES
- Indicator bulb
- Instrument cluster
