Torque Specifications
Torque SpecificationsTORQUE SPECIFICATIONS:
Flexplate
Tighten the Flexplate bolts to 45 Nm (33 ft. lbs.)
For final torque, rotate the flywheel bolts an additional 45° clockwise.
Fluid Pan
Tighten the bolts to 8 Nm (71 inch lbs.)
