P2561

(P2561) HVAC CONTROL MODULE REQUESTED MIL ILLUMINATION






Diagnostic Test
1. DTC PRESENT IN A/C HEATER CONTROL MODULE





This is an informational DTC letting you know that a DTC(s) is stored in the A/C Heater Control Module. Using the DRBIII, read the A/C-Heater Control Module DTC(s) and refer to the A/C Heater Control Module Category to perform the appropriate symptom. Erase this DTC from the PCM after all A/C-Heater Control Module DTC(s) have been repaired.
PCM Diagnostic Information complete.
Continue
Test Complete.
