Early Production (SBEC)

Test 1 - 2:






SYMPTOM
P1602-PCM NOT PROGRAMMED

WHEN MONITORED
Ignition key on

SET CONDITION
PCM has not been programmed.

POSSIBLE CAUSES
- PCM
