Map Light: Service and Repair

READING LAMP

REMOVAL
1. Disconnect and isolate battery negative cable.

Reading Lamp:

2. Using a trim stick, pry lamp from headliner.
4. Disconnect wire connector to lamp assembly.
5. Remove transmission range indicator bezel and lamp assembly from vehicle.

INSTALLATION
1. Position transmission range indicator bezel and lamp assembly to vehicle.
2. Connect wire connector to lamp assembly.
3. Engage tabs on transmission range indicator bezel to slots in rear floor console bezel.
4. Push downward on transmission range indicator bezel to engage to bezel to floor console.
