P1776

Symptoms:
P1776-SOLENOID SWITCH VALVE LATCHED IN LR POSITION

When Monitored and Set Condition: P1776-SOLENOID SWITCH VALVE LATCHED IN LR POSITION
When monitored: Continuously when doing partial or full EMCC (PEMCC or FEMCC).
Set condition: This DTC will set if the TCM senses the L/R Pressure Switch closing while performing PEMCC or FEMCC or after two unsuccessful attempts to perform PEMCC or FEMCC.

POSSIBLE CAUSES:
RELATED DTC P0841 PRESENT
L/R PRESSURE SWITCH INOPERATIVE
INTERMITTENT OPERATION
TRANSMISSION RELAY OUTPUT CIRCUIT OPEN
L/R PRESSURE SWITCH SENSE CIRCUIT OPEN
L/R PRESSURE SWITCH SENSE CIRCUIT SHORT TO GROUND
L/R PRESSURE SWITCH SENSE CIRCUIT SHORT TO VOLTAGE
TCM - SOLENOID SWITCH VALVE
