P0871

Symptoms:
P0871-OD PRESSURE SWITCH SENSE CIRCUIT

When Monitored and Set Condition: P0871-OD PRESSURE SWITCH SENSE CIRCUIT
When monitored: Whenever the engine is running.
Set condition: The appropriate DTC is set if one of the Pressure Switches are open or closed at the wrong time in a given gear.

POSSIBLE CAUSES:
TRANSMISSION RELAY DTCS PRESENT
INTERMITTENT WIRING AND CONNECTORS
TRANSMISSION RELAY OUTPUT CIRCUIT OPEN
O/D PRESSURE SWITCH SENSE CIRCUIT OPEN
O/D PRESSURE SWITCH SENSE CIRCUIT SHORT TO GROUND
O/D PRESSURE SWITCH SENSE CIRCUIT SHORT TO VOLTAGE
O/D PRESSURE SWITCH INOPERATIVE
TCM - O/D PRESSURE SWITCH
