P0846

Symptoms:
P0846-2/4 PRESSURE SWITCH SENSE CIRCUIT

When Monitored and Set Condition: P0846-2/4 PRESSURE SWITCH SENSE CIRCUIT
When monitored: Whenever the engine is running.
Set condition: The appropriate DTC is set if one of the Pressure Switches are open or closed at the wrong time in a given gear.

POSSIBLE CAUSES:
TRANSMISSION RELAY DTC'S PRESENT
INTERMITTENT WIRING AND CONNECTORS
TRANSMISSION RELAY OUTPUT CIRCUIT OPEN
2/4 PRESSURE SWITCH SENSE CIRCUIT OPEN
2/4 PRESSURE SWITCH SENSE CIRCUIT SHORT TO GROUND
2/4 PRESSURE SWITCH SENSE CIRCUIT SHORT TO VOLTAGE
2/4 PRESSURE SWITCH
TCM - 2/4 PRESSURE SWITCH CIRCUIT
