P0841

Symptoms:
P0841-LR PRESSURE SWITCH SENSE CIRCUIT

When Monitored and Set Condition: P0841-LR PRESSURE SWITCH SENSE CIRCUIT
When monitored: Whenever the engine is running.
Set condition: The appropriate DTC is set if one of the Pressure Switches are open or closed at the wrong time in a given gear.

POSSIBLE CAUSES:
LOSS OF PRIME DTC P0944 PRESENT
TRANSMISSION CONTROL RELAY DTCS PRESENT
TCM AND WIRING - L/R PRESSURE SWITCH
INTERMITTENT WIRING AND CONNECTORS
TRANSMISSION RELAY OUTPUT CIRCUIT OPEN
L/R PRESSURE SWITCH SENSE CIRCUIT OPEN
L/R PRESSURE SWITCH SENSE CIRCUIT SHORT TO GROUND
L/R PRESSURE SWITCH SENSE CIRCUIT SHORT TO VOLTAGE
TCM - L/R PRESSURE SWITCH CIRCUIT
